SECABO | TC5 Lite Heat Press, 38x38cm

     Secabo TC5

Top performance and high working comfort – Secabo LITE –

The development of the popular Secabo TC5 press into the LITE version opens up many new possibilities for users. Greater flexibility in selecting and configuring the device is enabled by the easy replacement of components. An advantage of the new LITE models is the possibility of equipping the device with additional elements, such as base or heating plates. The Secabo TC5 LITE transfer press is a modular, automatically opening press for working with many materials. It perfectly heat-applies prints to clothing and can be used to apply designs to glass, wood, cardboard and other flat surfaces. The press is equipped with an automatic opening system; after the set working time has elapsed, the press opens automatically. Operation can be interrupted at any time by pressing the stop button.

The temperature and pressing time are programmed using the digital controller. The pressing force is adjusted using a large manual knob on top of the heating plate. The SECABO TC5 LITE press, with a working area of 38 cm x 38 cm, has an additional heating-plate cover that protects the user from burns. The TC5 LITE design is fully modular: the central frame, heating plate, base plate and base frame can be removed and replaced in a few simple steps. For example, it is possible to use other heating plates or accessories such as the Quick Change System (for quickly changing work plates). LITE transfer presses offer everything that makes textile transfers from Secabo so convenient. The press is designed for all professional hot-transfer applications, such as flex films, flock film, elastic and hot-stamping films, sublimation, inkjet flex, etc.

     Key features of the Secabo TC5 Lite:

pressure adjustment: on the heating plate using a manual handwheel.
net weight: 39 kg
working area: 38 x 38 cm
max. working pressure: 250 g/cm²
max. clamp angle: 40°
maximum temperature: 225 °C
maximum time: 999 s
supply voltage power supply voltage: AC 230V / 50Hz - 60Hz, 2,0kW
environment: +5°C - +35°C / 30% humidity: 70%

     Additional accessories:

Quick Change System
Additional plates
Secabo Slider
Membrane plate
Heated lower plate
